Save Over $175 with our 1964 Chevelle JL Audio Stereo Kit. This stereo kit will add amazing sound quality and balance to your 1964 Chevelle . JL Audio is known in the car audio market for their high quality amplifiers, speakers and subwoofers. Every JL Audio product that is developed must pass the ear test of their
founders before being released so you know that you are getting audiophile grade components in your 1964 Chevelle . This kit includes the radio of your choice, a JL Audio C2 series dash speaker, a pair of JL Audio C2 6x9 speakers, your choice of amplifier, all the wiring needed to connect everything, and the option to add a loaded subwoofer enclosure.
There are the three different radio models. The USA-230 is a basic AM/FM radio with an Auxiliary input. The USA-630 is an AM/FM radio with an auxiliary input, a USB port, the ability to add Bluetooth via the BluKit, and the ability to add a CD player with our CD-1. The last model, the USA-740 has Bluetooth built in, an AM/FM tuner, subwoofer pre-out, USB, auxiliary input, the ability to add a CD-1 external CD player, and a 7 color LCD display.
For the JL Audio dual dash mount speaker, we mount two, JL Audio C2 speakers to one of the Custom Autosound direct fit speaker plates so that you get high quality stereo sound from a single speaker location. We use either 3.5" or 4" C2 series speakers, depending on the vehicle and whether or not it has air conditioning. The speaker size is determined by the vehicle and each application. There really is not much different between a 3.5" and a 4" and we use 4" whenever they fit. If the 4" will not work, we must use 3.5's.
The JL Audio C2 6x9's are some of the most efficient 6x9 speakers on the market. They come in a 3-way configuration and can mount both above or below the package tray, depending on your vehicle. If you have a perforated package tray and want to mount the speakers below for a super stealth look, you can with the JL Audio C2's. If not, just drop them in from above and the simple style of the grille looks great in the rear of ever classic car. These speakers really do sound great. They have silk dome tweeters which give rich, warm, well balanced sound.
For the amplifier, we offer two different 4 channel options, and the RD series 900 watt 5 channel amp. The 4 channel amps are for systems that will not have a subwoofer. If you want to add a subwoofer, go with the RD series 900 watt, 5 channel. The RD900/5 is an amazing amp and is super easy to tune thanks to the LED clipping indicator built in. For the 4 channel amps, if space is an issue or a concern, go with the 280 watt mini 4 channel. If you are not worried about space, the RD400/4 is a great piece and is probably worth upgrading. Full size amps will usually outperform, application specific, mini amps. However, if you want the JL quality but you are at the top of your budget, the MX280/4 mini is sitll a great product and you will still love the sound quality from your speakers.
Now to the subwoofers. Ahh yes, JL Audio subs. JL Audio is probably best known for their subwoofers and we offer three great options if you choose to add one. The 10" W0 has been around forever and is probably regarded as the best entry level subwoofer on the market. The W0's just simply perform and the 10" in the slot ported box will give you the low-end you want for home theater quality sound, but it isn't going to shake the earth and wake up your neighbors. The 10" W0 is in a somewhat large enclosure and if you are tight on space, the 8" W3 is simply amazing. The 8" W3 comes in a low profile, ported enclosure and is just simply awesome. It is an 8" woofer that performs and sounds like a 12" but without the need for the larger box. The last enclosure we offer with this package is a 12" TW3. The TW3 is the thin-mount version of the W3 and basically gives you full size output in a low-profile enclosure. Most low-profile subwoofers on the market sound like low-profile subwoofers as they just don't have the punch (think kick drum) that full size woofers do. Not the TW3. If you have the money and you want the best, go with the 12" TW3. You can always turn the bass down, but if you like your music loud and you want it to sound like it would if it were being played live, the 12" TW3 is the way to go.
We give you everything you need to wire everything up. Speaker wire, RCA's, and an amp wiring kit. Our helpful staff is available to help you with any questions you have with radio, speaker, amp, and subwoofer installation. We offer a two year warranty on the radio, and everything else is warrantied for a minimum of 1 year from JL Audio. If you have any other questions or concerns. give us a call or shoot us an email and we will be happy to help you out. Meanwhile, here are some helpful charts with the specs for each of the component options.
Radios
USA-230
Bluetooth
Optional (Add MBT-RX)
Key Features
⬤
AM/FM
⬤
Auxiliary Input (Rear)
⬤
4 Ch. RCA Pre-Outs
USA-630
Bluetooth
Optional (Add BluKit)
Key Features
⬤
AM/FM
⬤
Auxiliary Input (Rear)
⬤
4 Ch. RCA Pre-Outs
⬤
USB Port
⬤
Option to Add CD Player
USA-740
Bluetooth
Yes
Key Features
⬤
AM/FM
⬤
2 Auxiliary Inputs (Front & Rear)
⬤
4 Ch. + Subwoofer Pre-Outs
⬤
USB Port
⬤
Option to Add CD Player
⬤
Selectable 7 Color LCD Display
Speakers
JL Audio C2 Dash Speakers
Tweeter Material
Silk Dome (Soft Dome)
Surround
UV Resistant Foam
Features
⬤
Silk dome tweeter for smooth, rich, balanced sound tone
⬤
Consists of (2) 3.5" or 4" speakers mounted to a vehicle specific plate (Speaker size varies by application)
⬤
3.5" C2-350: 25W RMS/75W Peak
⬤
4" C2-400: 35W RMS/105W Peak
JL Audio C2 6x9s
Tweeters
Silk Dome (Soft Dome)
Surround
UV Resistant Foam
Features
⬤
Silk dome tweeter for warm, rich, balanced sound
⬤
Spacer rings included allowing for top or bottom mounting
⬤
93dB @ 1W/1M - Very efficient speakers
⬤
70W RMS/225W Peak
⬤
All around great sounding speakers
4 Ch. Amplifiers
Mini 280W 4 Ch.
Power Rating
50Wx4 @ 4 Ohms
70Wx4 @ 2 Ohms
Dimensions
Length: 8.66"
Width: 3.09"
Height: 1.77"
Subwoofer
None - 4 Channel
Features
⬤
Small chassis allows for flexible mounting
⬤
Legendary JL Audio quality in a super small package
⬤
Accpets high and low level inputs
⬤
280 watts of amplifier power blows away 300 watts of radio power
⬤
Great amp and significantly better sounding than just powering off of the radio. Perfect if you are tight on space.
RD Series 400W 4 Ch.
Power Rating
75Wx4 @ 4 Ohms
100Wx4 @ 2 Ohms
Dimensions
Length: 9.78"
Width: 6.96"
Height: 2.13"
Subwoofer
None - 4 Channel
Features
⬤
JL Audio quality at an affordable price point
⬤
LED clipping indicators for perfect gain setting
⬤
Noticeable sound quality difference versus the 280 watt mini
⬤
Worth the $50 upgrade. Better than the MX if you aren't tight on space or budget
XDM Series 400W 4 Ch.
Power Rating
75Wx4 @ 4 Ohms
100Wx4 @ 2 Ohms
Dimensions
Length: 8.52"
Width: 7.09"
Height: 2.05"
Subwoofer
None - 4 Channel
Features
⬤
More Actual Output than the RD despite the same rating
⬤
Better signal processing and thermal management than RD
⬤
Smaller than the RD400/4
⬤
The go-to "Good" JL Audio amp series. Nothing is spared or compromised with the XDM series amps.
⬤
Better than the RD series amps.
VXi Series 400W 4 Ch.
Power Rating
75Wx4 @ 4 Ohms
100Wx4 @ 2 Ohms
Dimensions
Length: 9.02"
Width: 6.62"
Height: 2.12"
Subwoofer
None - 4 Channel
Features
⬤
Built in, on-board, full DSP
⬤
10 bands of fully parametric EQ per output channel
⬤
Time delay down to .01 millisecond steps
⬤
Uses JL's NexD2 switching technology
⬤
The best sounding amp JL makes while giving you full control of each speaker. Perfect for audiophiles and/or those that like to tune and tinker.
5 Ch. Amplifiers
JL Audio RD900/5 900W 5 Ch.
Power Rating
70Wx4 + 225Wx1 @ 4 Ohms
100Wx4 + 500Wx1 @ 2 Ohms
Dimensions
Length: 14.66"
Width: 6.966"
Height: 2.13"
Subwoofer
Any
Features
⬤
JL Audio quality at an affordable price point
⬤
Perfect for powering 4 speakers + Sub
⬤
LED clipping indicators for perfect gain setting
⬤
Accepts high and low level inputs
⬤
900 watts of JL Audio power. Need we say more?
JL Audio XDM1000/5 1000W 5 Ch.
Power Rating
75Wx4 + 400Wx1 @ 4 Ohms
100Wx4 + 600Wx1 @ 2 Ohms
Dimensions
Length: 10.23"
Width: 7.09"
Height: 2.05"
Subwoofer
Any
Features
⬤
Compared to the RD, more actual output for hte speakers. Less rated power, but similar output for the subwoofer.
⬤
Better signal processing than the RD900/5
⬤
Smaller than the RD900/5
⬤
Accepts high and low level inputs
⬤
The XDM does not compromise. The XDM is the "go-to" quality line from JL before you get into the super high end stuff.
JL Audio VX700/5i 700W 5 Ch.
Power Rating
75Wx4 + 180Wx1 @ 4 Ohms
100Wx4 + 300Wx1 @ 2 Ohms
Dimensions
Length: 9.81"
Width: 6.62"
Height: 2.12"
Subwoofer
Any
Features
⬤
Built in, on-board, full DSP
⬤
10 bands of fully parametric EQ per output channel
⬤
Time delay down to .01 millisecond steps
⬤
Uses JL's NexD2 switching technology
⬤
This is essentially the XD700/5 but improved and with a full DSP built-in.
⬤
The best sounding amp JL makes while giving you full control of each speaker and your subwoofer. Perfect for audiophiles and/or those that like to tune and tinker.
Subwoofers
JL AUdio 10" W0
Power Handling
300W RMS
Dimensions
Width: 15.51"
Height: 13.77"
Top Depth: 14"
Bottom Depth: 17.38"
Wired Impedance
4 Ohms
Features
⬤
JL Audio W0 is the best performing entry level woofer on the market
⬤
W0 has been around forever. Tried, tested, proven quality
⬤
Slot ported enclosure design for improved output
⬤
Perfect if space isn't an issue
JL 8" W3v3
Power Handling
250W RMS
Dimensions
Width: 18.625"
Height: 11"
Depth: 5.125"
Wired Impedance
2 Ohms
Features
⬤
Dynamite in a small package
⬤
Low profile enclosure that sounds bigger than an 8"
⬤
One of our best selling woofers
⬤
Ported enclosure design allows for a small enclosure with BIG output
JL 10" TW1
Power Handling
300W RMS
Dimensions
Width: 15"
Height: 11.75"
Depth: 5.563"
Wired Impedance
2 Ohms
Features
⬤
Thin woofer in a very compact box
⬤
More compact, and hits harder than the 10" W0 & 8" W3
⬤
Hits harder and sound cleaner and tighter than you would expect
⬤
A lower cost, "baby" version of the TW3
JL 12" TW3
Power Handling
400W RMS
Dimensions
Width: 23.75"
Height: 15.625"
Depth: 5.0625"
Wired Impedance
2 Ohms
Features
⬤
Thin woofer with full size bass output
⬤
Legendary JL Audio sound quality
⬤
Worth the upgrade if you have the money to spend
